When Microseconds Equate to Millions of Dollars – Latency And Optical Networks for High Frequency Trading (HFT)

High frequency trading (HFT) firms continue to make the news with demand for ultra-low latency (ULL) networks. The recent announcement by ZAYO Group that an HFT firm had signed up for their ULL network, including dark fiber and a wavelength solution, is just one example. In this article, the effort by the industry to mitigate latency in support of HFT and other low latency applications is examined.

About high frequency trading

High-Frequency or Algorithm trading is a type of financial trading that uses powerful computers and complex algorithms to execute a large number of orders at extremely high speeds.

Imagine that you are playing a video game where you need to make moves and decisions in milliseconds to win; HFT is somewhat similar, but in the world of stock markets.

The computer swiftly analyzes the market, determining when to buy or sell, and promptly executes these decisions at a rate that is humanly impossible. This often happens in milliseconds, where a millisecond is thousandth of a second.

HFT firms make money on very small price differences, often just a few cents or fractions of a cent. Because the profit per trade is so small, they need to make a huge number of trades to generate significant profits. This means they often trade millions of shares each day.

Regardless of the strategies employed by high-frequency traders, it is crucial for their computers to be very fast and efficient, and the latency—the time taken for data bits to travel the link between HFT’s firm systems and the stock exchange—must be minimized. High-frequency traders go to great lengths to decrease this latency, understanding that even a millisecond edge over their rivals can lead to significantly increased earnings.




For more on high frequency trading you can also read Michael Lewis’s book, Flash Boys: A Wall Street Revolt.

While some traders have been able to drastically reduce latency by collocating with the stock exchange and optimizing the server processing speed, some must access more than one exchange such as Chicago and New York or London and Frankfurt. As a result, optical networks connecting financial institutions between these locations must be optimized for latency. The most important contributors to latency in an optical network are the transmission fiber, dispersion compensating fiber and the process of optical to electrical conversion or vice versa. We will look at latency and its mitigation in these components and processes.

Latency in optical fibers

Optical fiber is the most important contributor of latency in a long-distance optical communication network. The length of the optical fiber represents the distance traveled by communication signals from one point to another. While the light travels at a speed of 299,792km/s in free space, the speed is reduced to about 204,190km/s in a standard single mode (ITU-G.652 compliant) fiber. The ratio of the free space speed to speed in fiber is the group refractive index of the fiber which is 1.4682 in this case.

The above speeds translate to latencies of 3.34µs/km in free space and 4.90µs/km in the standard single mode fiber. While these values are insignificant for most communication applications, they have a profound impact on latency sensitive applications such as the HFT discussed above. The optical network engineer must perform meticulous calculations and procure the lowest latency fiber available to minimize the overall latency of the network or link.\

A number of manufacturers are optimizing their manufacturing processes to reduce latency, even if it is by a tiny amount. The following table shows the performance of two of the industry’s leading fiber optic brands. While the latency values for these fibers look almost the same, the difference in latency between the two extremes translates to 21µs over 1,000km, a significant value in HFT.

BrandFiber TypeWavelength(nm)IndexLatency (µs/km)
Brand A-1ITU G.65215501.46204.877
Brand A-2ITU G.65215501.46824.897
Brand B-1ITU G.65215501.46204.877
Brand B-2ITU G.65215501.46704.893

Even when traders are collocated with the stock exchange servers, they still put an effort to squeeze out whatever latency they can to get an urge over the competition. With HFT, researchers working on hollow core, photonic crystal fiber (PCF), have found an extra incentive for their work. When commercialized, these fibers could play a pivotal role in HFT and other low latency applications.

Photonic crystal (or photonic band gap) fiber is a new type of fiber based on a special class of optical medium with periodic modulation of refractive index. The structure of a hollow core fiber is shown in the picture.  photonic-crystal-fiber

Because of the absence of glass in the core, light in a hollow core fiber travels close to the speed of light in a vacuum – significantly reducing the latency. Researchers from Infinera, Molex, Lumentum and OFS Fitel have demonstrated that hollow core fiber can reduce latency by 30%. See their publication on Researchgate – Transmission of Commercial Low Latency Interfaces over Hollow-Core Fiber.

Latency in dispersion compensating fiber

One important impairment that occurs in optical fibers in long distance optical networks is chromatic dispersion. A phenomenon caused by the wavelength dependence of refractive index, chromatic dispersion (or simply dispersion) causes the broadening of digital pulses. The transmission fiber must be compensated for dispersion before pulse broadening result in the interference of adjacent symbols and distort the signal. The compensating modules are typically inserted on transmission spans between erbium doped fiber amplifiers (EDFAs) – see illustration.

dcm-latency-in-high-frequency trading

Typical dispersion compensating modules consist of special type of optical fiber with negative dispersion relative to the transmission fiber. The length of the dispersion compensating fiber introduces additional latency in the network. A typical DCF module required to compensate 80km of standard (ITU-G.652) fiber at 1550nm introduces at least 60ns of latency in the network. With multiple spans on a link, the latency quickly adds up.

Non-zero dispersion shifted fiber (NZDSF) such as ITU-T G.655 or ITU-T G.656 fiber is sometimes used to reduce the number of DCMs in the network. NZDSF has significantly lower dispersion in the C-band (around 1550nm) transmission window and requires fewer compensating modules and therefore it enables lower latency networks.

As an alternative, dispersion compensating Bragg gratings (FBG) are used for compensation because they introduce negligible latency in the system. A FBG is a fiber based device that reflects light due to the modulation of its core refractive index. Light propagating in the grating is reflected if its wavelength matches the periodicity of the core modulation. Selective reflection of components of light at different positions along the grating is used to compensate for incoming high dispersion light. See the article, Fiber Bragg Gratings: A Versatile Approach to Dispersion.

Because Bragg gratings are significantly shorter than dispersion compensating fiber, they introduce significantly less latency.

O-E or E-O conversion and latency

In certain cases, it is inevitable that transmission signals are converted from electrical to optical and vice versa. The conversion process introduces a delay which manifests itself as network latency. Transponders and muxponders are some of the network components that operate on O-E or E-O conversion. A transponder takes a short reach LAN optical signal, converts it to electrical and then back to optical while modifying it to a specific DWDM wavelength for transmission over a long distance. A muxponder, on the other hand, takes low transmission speed signals, multiplex them together into a higher speed signal with a specific DWDM wavelength.

Both transponders and muxponders can introduce significant levels of latency in the network, up to 10µs. Manufacturers are making every effort to improve their manufacturing processes to reduce the latency.

Summary:

While several applications such as VoIP and gaming are requiring improvement in network latency, it is the high frequency trading application that is demanding the most stringent latency specifications. The industry is focusing on different parts of the optical communication network to reduce latency. A lot of focus to improve latency is on transmission fiber, dispersion compensating fiber and E-O and O-E conversion.
